The MB23 provides precise moisture content determination at an unbeatable value. With a large backlit LCD display, standard RS232 port, 110g capacity with a readability of 0.01g/0.1% and an non-glass infrared heating element, the MB23 offers moisture analysis for any budget.
Percent Moisture Determination, Percent Solid Determination, Weighing
Backlit liquid crystal display (LCD)
Power cord (included)
Infrared heat source, ABS housing, metal pan support, metal pan handler, in-use cover
3 shut off criteria (manual, timed or auto), 1 standard heating profile, 50° to 160° C heating range (5° C increments)
Readability (> 10g sample): 0.1%
Repeatability (3g sample): 0.3%
Repeatability (10g sample): 0.2%
The minimum sample volume: 0.5g
Recommended amount of sample: 3 ~ 20g
Pan size: Diameter 90mm
Temperature program: Standard
Environmental Operating temperature: 10 ° C -30 ° C
Communication: RS232 bidirectional
Endpoint control: timer, automatic
Heating temperature: 50 ° C to 160 ° C (5 ° C of a ladder)
Display: Moisture% solids%, weight, time, temperature
Heating time: 1 to 60 minutes 30 seconds of the step size, the step size of 60 to 90 minutes to 1 minute
Dimensions (width × height × length): 165 × 127 × 280mm
Total weight: 4.15kg
Sample pan handle: Standard
Heating source: infrared heating
The MB23 utilizes a metallic sheathed - no glass infrared heating element for drying of samples.
With a bright backlit LCD and easy one-button setup and menu navigation, MB23 is extremely user-friendly.
MB23 is very easy-to-clean to ensure the integrity of your samples and its compact design allows it to fit seamlessly into most workspaces.
