Function & Feature:
l English menu
l Two patterns of working: pattern of direct and pattern of group.
l Two methods of power off: Manual & Automatically
l Show battery information in real time
l Limit settings: alarm if one of the measurement data is beyond of the limits.
l Deleting function: You can delete one of the doubtful data
and you can also delete all of data in the memory to prepare for new measurement.
l Saving function: capable of 500 sets of measurement value.
l Two optional methods available to calibrate the gauge,
and you can calibrate system error of the probe using basic calibration method.
l Five statistical data: Mean ValueMaximum Value, Minimum Value,
Measurement, Standard Deviation.
Application Fields:
l Coating thickness gauge is mainly used for measuring hull,
oil and gas pipeline, high pressure vessel and boiler wall thickness as well as
a variety of plate thickness, can be measured material is a delegate with steel metal materials,
can be plastic, nylon and other non-metallic materials.
Measuring Material:
l non conductive coatingo non magnetic metal
(such as rubber, plastic, paint, oxide aluminum, copper, zinc, tin)
Technical Specification
|
Model
|
leeb221
|
|
Operating principle
|
Eddy current
|
|
Measuring range (µm)
|
0~1250μm
|
|
Accuracy
|
±[">(1~3%)H+1]
|
|
Low range resolution (µm)
|
0.1μm
|
|
Min curvature of the min area (mm)
|
Convex1.5 Concave9
|
|
Diameter of the min area (mm)
|
Φ7
|
|
Critical thickness of substrate (mm)
|
0.5
|
|
Operating temperature
|
0ºC~40ºC
|
|
Dampness
|
20%~90%
|
|
Magnetic field
|
No strong magnetic field environment
|
|
Memory
|
500 measured data
|
|
Dimensions
|
150×55.5×23mm
|
|
Power supply
|
AAA Alkaline battery
|
|
Standard configuration
|
Unit Probe Matrix,5 specimens (50mm, 100mm,
200mm, 500mm, 1000mm), 2AAA Batteries
|
|
Optional Accessories
|
Optional probes for Leeb222
|
